Key Specifications
Display-
TFT color display, 128x160 pixels
Sensor-
Accelerometer
Sensitivity- l00mV/g
Vibration
Measurement Range- Velocity: 0-200mm/s RMS,
Displacement: 0-2000m Peak-Peak, Acceleration: 0-20 g Peak, BG: 0-20g Peak
Frequency Range:
velocity, displacement acceleration (10-1,000Hz),
Bg - Hi Frequency Acceleration (1,000-12,000Hz)
Accuracy- +/-5%
Alarm Indication- Built-in ISO 10816-3 equipment vibration level standard (intelligent colour indication)
Temperature- -20 ·C to 120°C or -5°F to +250°F
Accuracy- ±2°C; Resolution: 1 °C;
Power & Charger-
Lithium rechargeable
battery, 3.7V 1600 mAh, Recharge time 3 hours,
Operating time >30 hours continuous
Operation temperature- -10C-50C
