True RMS Power Measurement: Accurately measures true power (Watts) even in non-linear loads, providing critical insights into energy consumption.
Simultaneous Measurement: Measures key parameters simultaneously, including current, voltage, power, power factor, and energy consumption, for a comprehensive understanding of electrical systems.
Wide Measurement Range: Capable of measuring a wide range of AC currents, covering a variety of applications from small appliances to large industrial equipment.
High Accuracy: Delivers precise measurements with minimal error, ensuring reliable data for energy analysis and troubleshooting.
Compact and Lightweight: Portable and easy to use in tight spaces, making it ideal for field service and maintenance.
Large, Backlit Display: Ensures clear visibility of readings in various lighting conditions.
Data Logging Capability: Stores measurement data for later analysis and reporting, helping to identify energy-saving opportunities.
Bluetooth Connectivity: Enables wireless data transfer to mobile devices or computers for easy data management and analysis.
Long Battery Life: Provides extended operation time on a single charge, minimizing downtime.
Safety Features: Equipped with safety features to protect the user from electrical hazards.
Key Technical Specifications:
Current Measurement
AC Current Range: 0.060A to 600.0A.
Capable of handling low and high current systems accurately.
Voltage Measurement
AC Voltage Range: 80.0V to 600.0V.
Compatible with standard and high-voltage electrical systems.
True RMS Technology
Ensures precise readings even for distorted waveforms and non-linear loads.
Power Factor and Phase Angle
Measures Power Factor (PF) and Phase Angle for advanced power quality analysis.
Harmonic Measurement
Analyzes up to the 30th harmonic, allowing detection of waveform distortions.
Jaw Opening Size
46mm (1.8 inches): Accommodates large-diameter cables and busbars.
Data Logging and Connectivity
Wireless capability via GENNECT Cross App for data transfer, visualization, and reporting (requires optional adapter).
Durability and Design
IP54-rated dustproof and waterproof design for rugged field use.
Compact and lightweight for easy portability.
Display Features
Large, easy-to-read backlit LCD display for clear visibility in low-light conditions.
