Key Technical Specifications:
Voltage and Current Measurement
- AC/DC Voltage: Up to 600V for high-capacity testing.
- AC/DC Current: Up to 10A for versatile current diagnostics.
- True RMS (TRMS) technology ensures precise readings, even with non-linear waveforms.
Variable Frequency Drive (VFD) Mode
- Specially designed for variable frequency drive (VFD) systems, offering accurate voltage and frequency measurements in complex environments.
Resistance, Capacitance, and Frequency
- Resistance: 0.1Ω to 50MΩ for comprehensive circuit analysis.
- Capacitance: 1nF to 10,000µF, suitable for capacitor testing.
- Frequency: 0.1Hz to 100kHz for extensive frequency diagnostics.
Temperature Measurement
- Measures temperature from -40°C to +400°C (-40°F to 752°F) with a Type K thermocouple.
- Ideal for HVAC and industrial applications.
Continuity and Diode Testing
- Audible continuity tester for quick circuit troubleshooting.
- Diode testing mode included for checking semiconductor functionality.
Safety and Compliance
- Rated CAT IV-300V / CAT III-600V for reliable operation in high-voltage environments.
- Fully compliant with IEC 61010 safety standards.
Display Features
- Large, easy-to-read backlit display with high-resolution output.
- Analog bar graph for real-time measurement trends.
Power Supply
- Operates on two AA batteries with an auto power-off function to conserve battery life.
Design and Build
- Rugged, durable design with an ergonomic grip for comfortable handling.
- Compact and lightweight, perfect for fieldwork.
