Key Technical Specifications:
Current Measurement Range
- AC Current: 0.1A to 600A True RMS.
- DC Current: 0.1A to 600A.
- Accurate for diverse current measurement applications.
Voltage Measurement Range
- AC Voltage: 0.1V to 1000V True RMS.
- DC Voltage: 0.1V to 1000V.
- Ideal for detailed electrical diagnostics.
Power Measurement
- Active Power (W): 10W to 600kW.
- Reactive Power (VAR): 10VAR to 600kVAR.
- Apparent Power (VA): 10VA to 600kVA.
- Comprehensive analysis of power systems.
Harmonics Analysis
- Measures Total Harmonic Distortion (THD).
- Provides detailed insights into waveform distortions.
Frequency Measurement
- Range: 20Hz to 9.999kHz.
- Accurate monitoring of system frequency.
Resistance and Continuity Testing
- Resistance Range: Up to 60kΩ.
- Ensures precise troubleshooting.
Capacitance Measurement
- Range: Up to 3.999mF.
- Useful for component and circuit analysis.
Wireless Connectivity
- Equipped with Bluetooth METERLiNK® for real-time data transfer to FLIR thermal imaging cameras and mobile devices.
True RMS Technology
- Ensures accurate readings for both sinusoidal and non-sinusoidal waveforms.
Jaw Opening Capacity
- Maximum Diameter: 37mm
- Compatible with thick conductors and bus bars.
Safety Ratings
- CAT IV 600V, CAT III 1000V: Maximum safety for high-voltage environments.
Display
- Large, backlit dual display for clear visibility in all lighting conditions.
- Bar graph display for real-time trend analysis.
Inrush Current Measurement
- Detects startup currents for motors and equipment.
Data Logging and Memory
- Stores measurement data for on-site analysis.
- Exportable data for enhanced reporting.
Durable and Rugged Design
- Built for demanding environments with impact-resistant housing.
