FLIR TG298 High Temperature Thermal Camera with Bullseye Laser

https://www.dotearth.ae/web/image/product.template/2290/image_1920?unique=af1afe7
(0 review)

Model No: TG298

3,299.00 AED 3299.0 AED 3,299.00 AED 3,369.00 AED

Not Available For Sale

  • Brand
  • Warranty

This combination does not exist.

Contact Us
Brand: Flir
Warranty: 1 Year

Share

Key Features:

Ultra‑wide temperature range up to 1080 °C (1976 °F) – Allows measurement of extreme‑heat environments such as kilns, forges, glass furnaces, smelting and industrial manufacturing.

30 : 1 spot size ratio with bullseye laser pointer – Enables accurate targeting at a distance, making it easier to pinpoint hot spots without contact.

MSX® image enhancement and Super Resolution technology – The camera uses FLIR’s MSX to emboss visible‑light details on thermal images + upscales the native 160×120 detector effectively to 320×240 for sharper imagery.

Large field of view: 57° × 44° and focus‑free optics – Allows broad scene capture without needing to adjust focus manually, speeding up inspections.

Built‑in LED work‑light + rugged design (IP54, 2 m drop tested) – Provides extra usability in dark or poorly lit work zones, and rugged durability for industrial job‑site conditions.

Connectivity via Bluetooth (METERLiNK® app) + internal memory for image/video capture – Enables remote monitoring, sharing of inspection data and efficient reporting from the field.

High thermal sensitivity: NETD < 70 mK – Ensures the camera can detect subtle temperature differences and potential faults more reliably.

Accurate readings across broad object temperature ranges with emissivity correction – Provides measurement confidence even when working with high temperatures or varying surface properties.



Key Technical Specifications:

IR Resolution: 160 × 120 pixels (with Super Resolution upscaled to 320 × 240)

Object Temperature Range: –25 °C to 1080 °C (−13 °F to 1976 °F)

Thermal Sensitivity (NETD): < 70 mK

Accuracy: ±2.5% or ±2.5 °C (for 0 °C to 50 °C & 100 °C to 400 °C) / ±3% or ±3 °C (for –25 °C to 0 °C & >400 °C)

Field of View (FOV): 57° × 44°

Display: 2.4‑inch colour LCD, resolution 320 × 240 pixels

Built‑in Laser Pointer: Bullseye laser (Class 1) to indicate measurement spot on target

Focus: Focus‑free optics (minimum focus distance ~0.3 m)

Spectral Range: 7.5 µm – 14 µm

Storage: 8 GB internal memory for image capture

Connectivity: Bluetooth via the METERLiNK® app for remote monitoring & documentation

Environmental & Durability: IP54 rated enclosure, drop‑tested to 2 m height

Power: Rechargeable Li‑ion battery, approx. 5 h continuous scanning with laser off (≈4.5 h with laser on)

Tripod Mount: Standard ¼‑20 UNC thread for mounting on tripod/handle base
