Key Features:
Wide-Range Pressure Measurement Support
Accepts interchangeable pressure transducers in 30, 150, and 300 psi ranges
(sold separately), allowing versatile use across low-, mid-, and high-pressure
applications.
Automatic Transducer Recognition
The meter automatically detects the connected transducer’s range and
calibration, ensuring accurate pressure readings without manual setup.
Multi-Unit Pressure Display
Displays pressure in up to 10 selectable units, including bar, psi,
kg/cm², hPa, mmHg, inHg, meters H₂O, kPa, and inH₂O, for greater flexibility in
various industries.
Advanced Data Logging Capabilities
Adjustable sampling rate from 1 second up to 8 hrs 59 min 59 sec, with storage
of up to 20 million readings on an SD card in Excel® format —
perfect for long-term monitoring and analysis.
On-Board Memory & Manual Logging
Store up to 99 manual readings and recall MIN/MAX values directly
on the device for quick performance checks.
Large Backlit Dual LCD Display
Easy-to-read dual backlit LCD enhances visibility in dim environments,
making field pressure checks faster and more reliable.
Offset & Zero Adjustment Feature
Built-in offset adjustment for zeroing the meter enables accurate relative
pressure measurement and calibration refinement.
Built-In PC Interface
Connects to a computer via RS-232/USB, enabling seamless data transfer
and integration with analysis software.
Data Hold & Auto Power Off
Freeze current readings with Data Hold, and conserve battery life with automatic
power-off (disable option available).
Complete Kit for Field Use
Includes SD card, hard carrying case, and 6 AA batteries,
making the unit ready for mobile pressure testing out of the box.
Durable & Industrial-Grade Design
Built for demanding work environments in industrial, manufacturing, HVAC/R,
and furnace systems.
