Polarization Index (PI) and Dielectric Absorption Ratio (DAR) calculations for insulation quality assessment
High-resolution backlit LCD display for easy readings in any lighting condition
Safety & Protection
CAT III-300V
safety rating for industrial applications
Built-in discharge function to eliminate residual voltage after testing
Live circuit detection prevents accidental damage
User-Friendly Operation
Large rotary switch for easy test voltage selection
Auto-ranging and auto power-off to extend battery life
Lock feature for hands-free testing
Durable & Portable Design
Rugged, impact-resistant housing for harsh environments
Compact and lightweight for easy portability
Power Supply & Battery Life
Rechargeable battery for long-lasting operation
Low battery indicator to prevent unexpected shutdowns
Technical Specifications:
Test Voltage Options: 500V, 1000V, 2500V, 5000V Insulation Resistance Range: Up to 60GΩ Polarization Index (PI) & Dielectric Absorption Ratio (DAR): Built-in automatic calculations Discharge Function: Automatically eliminates residual voltage Display: Large backlit LCD for clear readings Safety Rating: CAT III 300V for industrial environments Power Supply: Rechargeable battery with low battery indicator Auto Power-Off: Extends battery life Weight & Dimensions:
7.9lbs (3.6kg) & 13x10.2x6.3" (330x260x160mm)
