Extech EX820: 1000A True RMS AC Clamp Meter with IR Thermometer

https://www.dotearth.ae/web/image/product.template/2029/image_1920?unique=b4f68ec
(0 review)

729.00 AED 729.0 AED 729.00 AED VAT Excluded 759.00 AED

729.00 AED VAT Excluded 759.00 AED

Not Available For Sale

    This combination does not exist.

    Contact Us
    Brand: Extech Instruments
    Warranty: 1 Year


    Name: Extech EX820: 1000A True RMS AC Clamp Meter with IR Thermometer

    ​Key Features:

    • Measure High Currents with Precision: Accurately measure AC currents up to 1000 Amps with True RMS technology, ensuring reliable readings even on distorted waveforms.
    • Non-Contact Temperature Measurement: Quickly and safely measure surface temperatures of electrical panels, motors, and other equipment with the integrated IR thermometer, enhancing safety and efficiency.
    • Rugged and Durable: Built to withstand the demands of professional use with a robust design and protective holster.
    • Backlit Display: Ensures clear visibility in low-light conditions.
    • Data Hold & Min/Max Recording: Capture and store key readings for easy data analysis and troubleshooting.


    ​Key Technical Specifications:

    • AC Current Measurement: Measures up to 1000A AC with True RMS accuracy, ensuring precise readings in complex electrical systems.
    • Voltage Measurement: Measures AC/DC voltage up to 600V for versatile electrical diagnostics.
    • True RMS Technology: Provides accurate readings in noisy or distorted waveforms.
    • Integrated IR Thermometer: Non-contact infrared thermometer with laser pointer to measure surface temperatures from -50°C to 260°C (-58°F to 500°F).
    • Resistance and Continuity: Measures resistance up to 40MΩ with audible continuity for verifying connections.
    • Capacitance Measurement: Reads capacitance values up to 4,000µF, ideal for troubleshooting motors and capacitors.
    • Frequency Measurement: Frequency range of 0.001kHz to 4kHz for testing electronic equipment and systems.
    • Clamp Jaw Opening: Fits conductors up to 43mm (1.7 inches) for handling large cables.
    • Data Hold Function: Retains readings on the display for convenient analysis.
    • Min/Max Function: Captures minimum and maximum values for monitoring fluctuations.
    • Auto Power Off: Conserves battery life with automatic shut-off when idle.
    • Backlit LCD Display: Large, easy-to-read display with backlight for working in low-light conditions.
    • Safety Rating: CAT III 600V rated for safe operation in high-energy environments.
    • Durable Design: Built to withstand demanding field conditions with rugged construction.
    • Accessories Included: Comes with test leads, Type K thermocouple probe for temperature measurement, carrying case, and 9V battery.
