Extech 380396 High Voltage Digital Insulation Tester

https://www.dotearth.ae/web/image/product.template/2105/image_1920?unique=96f217c
(0 review)

3,199.00 AED 3199.0 AED 3,199.00 AED 3,219.00 AED

Not Available For Sale

  • Brand
  • Warranty

This combination does not exist.

Contact Us
Brand: Extech Instruments
Warranty: 1 Year

Share

​Key Features:

High Test Voltage Range: Supports 500V, 1000V, 2500V, 5000V
High Accuracy: Delivers ±2.5% accuracy for reliable readings in demanding environments.
PI (Polarization Index) & DAR (Dielectric Absorption Ratio) Measurement: Provides a detailed assessment of insulation quality over time.
Backlit Digital LCD Display: Large, easy-to-read screen with dual display and analog bar graph for enhanced visibility.
Automatic Discharge Function: Ensures safe operation by discharging capacitive voltage after testing.
Live Circuit Detection: Prevents testing if voltage exceeds 600V, protecting both the user and the device.
Programmable Test Timer: Allows preset test durations for consistent insulation testing.
Lock Power-On Feature: Enables hands-free operation for long-duration testing.
Data Hold & Memory Storage: Retains and recalls test data for analysis and reporting.
Auto Power-Off: Extends battery life by shutting down when inactive.
Durable & Portable Design: Built for field use with a rugged, ergonomic design.
Power Supply: Operates on rechargeable batteries or an AC adapter for flexible use.


​Technical Specifications:

Test Voltage Options: 500V, 1000V, 2500V, 5000V
Insulation Resistance Range: ​ 0 to 6MΩ , 0 to 60MΩ , 0 to 600MΩ , 0 to 6GΩ , 0 to 60GΩ
Measurement Accuracy: ±5% for reliable and precise readings
Polarization Index (PI) & Dielectric Absorption Ratio (DAR): Automatic calculations for insulation assessment
Display: Large backlit digital LCD with dual display and analog bar graph
Live Circuit Detection: Prevents testing if voltage exceeds 600V
Automatic Discharge: Safely discharges residual voltage after testing
Programmable Test Timer: Allows preset durations for automated testing
Power Source: Operates on rechargeable batteries or an AC adapter
Memory Function: Stores test results for data recall and analysis
Safety Compliance: CAT IV 600V for high-voltage applications
 Auto Power-Off: Enhances battery life by shutting down after inactivity
Weight & Dimensions: 3.2lbs (1438g) & 7.8 x 5.8 x 3.4" (198 x 148 x 86mm)
