Extech 380396 High Voltage Digital Insulation Tester

https://www.dotearth.ae/web/image/product.template/2105/image_1920?unique=5ab1120
(0 review)

3,199.00 AED 3199.0 AED 3,199.00 AED VAT Excluded 3,219.00 AED

3,199.00 AED VAT Excluded 3,219.00 AED

Not Available For Sale

    This combination does not exist.

    Contact Us
    Brand: Extech Instruments
    Warranty: 1 Year


    Name: Extech 380396 High Voltage Digital Insulation Tester

    ​Key Features:

    High Test Voltage Range: Supports 500V, 1000V, 2500V, 5000V
    High Accuracy: Delivers ±2.5% accuracy for reliable readings in demanding environments.
    PI (Polarization Index) & DAR (Dielectric Absorption Ratio) Measurement: Provides a detailed assessment of insulation quality over time.
    Backlit Digital LCD Display: Large, easy-to-read screen with dual display and analog bar graph for enhanced visibility.
    Automatic Discharge Function: Ensures safe operation by discharging capacitive voltage after testing.
    Live Circuit Detection: Prevents testing if voltage exceeds 600V, protecting both the user and the device.
    Programmable Test Timer: Allows preset test durations for consistent insulation testing.
    Lock Power-On Feature: Enables hands-free operation for long-duration testing.
    Data Hold & Memory Storage: Retains and recalls test data for analysis and reporting.
    Auto Power-Off: Extends battery life by shutting down when inactive.
    Durable & Portable Design: Built for field use with a rugged, ergonomic design.
    Power Supply: Operates on rechargeable batteries or an AC adapter for flexible use.


    ​Technical Specifications:

    Test Voltage Options: 500V, 1000V, 2500V, 5000V
    Insulation Resistance Range: ​ 0 to 6MΩ , 0 to 60MΩ , 0 to 600MΩ , 0 to 6GΩ , 0 to 60GΩ
    Measurement Accuracy: ±5% for reliable and precise readings
    Polarization Index (PI) & Dielectric Absorption Ratio (DAR): Automatic calculations for insulation assessment
    Display: Large backlit digital LCD with dual display and analog bar graph
    Live Circuit Detection: Prevents testing if voltage exceeds 600V
    Automatic Discharge: Safely discharges residual voltage after testing
    Programmable Test Timer: Allows preset durations for automated testing
    Power Source: Operates on rechargeable batteries or an AC adapter
    Memory Function: Stores test results for data recall and analysis
    Safety Compliance: CAT IV 600V for high-voltage applications
     Auto Power-Off: Enhances battery life by shutting down after inactivity
    Weight & Dimensions: 3.2lbs (1438g) & 7.8 x 5.8 x 3.4" (198 x 148 x 86mm)
