Key Technical Specifications:
Number of Screens
1
Screen Size Class
24"
Viewable Screen Size
23.8"
Screen Mode
Full HD
Panel Technology
In-plane Switching (IPS) Technology
Response Time
5 ms
Response Time Details
Aspect Ratio
16:9
Pixel Pitch
0.2745 mm x 0.2745 mm
Horizontal Viewing Angle
178°
Vertical Viewing Angle
178°
Mount Type
Panel Mount
Backlight Technology
LED Edgelight System
HDCP Supported
Yes
Tilt Angle
-5° to 21°
Features
- 3-sided Bezel Less
- Mercury-free
- Arsenic-free Glass
- Security Lock
- Anti-glare
- Cable Lock Slot
- BFR Free
- PVC Free
- Eye Comfort Technology
Horizontal Frequency
30 kHz to 82 kHz
Vertical Frequency
- 50 Hz to 76 Hz
- 50 Hz to 100 Hz - HDMI 1.4
Stand Adjustments
Tilt
Stand Included
Yes
Glass Hardness
3H
Operation Hours
12 Hours/7 Days
Maximum Resolution
1920 x 1080
Standard Refresh Rate
100 Hz
Color Supported
16.7 Million Colors
Native Contrast Ratio
1,000:1
Brightness
250 cd/m2
Color Gamut
72% NTSC (CIE 1931)
Pixel Per Inch (PPI)
93
Maximum Preset Resolution
- VGA: 1920 x 1080 at 60 Hz
- HDMI: 1920 x 1080 at 100 Hz
Connectivity
Video port
- 1 HDMI port (HDCP 1.4) (Supports up to FHD 1920 x 1080 100 Hz as per specified in HDMI 1.4)
- 1 VGA port
Non-operating Temperature Range
-4°F (-20°C) to 140°F (60°C)
Operating Humidity Range
10% to 80% (Non-condensing)
Non-operating Humidity Range
5% to 90% (Non-condensing)
Maximum Operating Altitude
16404 ft
Maximum Non-operating Altitude
40000 ft
Input Voltage Range
100V AC to 240V AC
Operating Power Consumption
12.80 W
Standby Power Consumption
0.3 W
Off-Mode Power Consumption
0.3 W
Frequency
Maximum Power Consumption
28.50 W
Voltage Current
700 mA
VESA Mount Compatible
Yes
VESA Mount Standard
100 x 100
Height
12.76"
Width
21.21"
Depth
1.88"
