Key Technical Specifications:
Current Measurement Range
- AC Current: 0.15A to 2000A True RMS.
- DC Current: 0.15A to 3000A.
- Designed for high-precision current measurement in industrial systems.
Voltage Measurement Range
- AC Voltage: 0.1V to 1000V RMS.
- DC Voltage: 0.1V to 1000V.
- Handles high-voltage applications with superior accuracy.
True RMS Technology
- Ensures accurate measurements for both sinusoidal and non-sinusoidal waveforms, critical for modern power systems.
Resistance Measurement
- Range: 0.1Ω to 99.99kΩ.
- Enables circuit testing and fault diagnostics.
Frequency Measurement
- Range: 5Hz to 20kHz.
- Provides precise frequency analysis for AC systems.
Power Measurement
- Measures active, reactive, and apparent power, along with power factor for in-depth energy analysis.
- Ensures comprehensive insights into electrical system performance.
Harmonic Analysis
- Supports harmonic measurements up to the 25th order for power quality monitoring.
Jaw Opening Capacity
- Maximum Conductor Size: 60mm.
- Capable of handling large cables and busbars.
Safety Ratings
- CAT IV 1000V: High-level protection for industrial and utility-grade environments, ensuring operator safety.
Inrush Current Measurement
- Accurately captures transient currents during equipment startup or system changes.
Data Logging and Storage
- Memory Capacity: Stores up to 300 measurements for tracking and analysis.
- Ideal for maintenance and diagnostic reporting.
Display
- Large backlit LCD with an integrated bar graph for easy reading in any lighting condition.
Durability
- Built to withstand rugged industrial environments with a robust design.
Operating Temperature Range
- Suitable for extreme environments, ensuring reliable operation over a wide temperature range.
